Anritsu MP1026A Bit Master Eye Pattern Analyzer 20 GHz 10 Gbps w/ Opts 002 & 003

$22,500.00

(No reviews yet) Write a Review

SKU:: 273441626670
Condition:: Refurbished
Brand:: Anritsu
MPN:: MP1026A
Model:: MP1026A

Anritsu MP1026A Bit Master Eye Pattern Analyzer 20 GHz 10 Gbps w/ Opts 002 & 003

Current Stock:

Quantity:

Product Description

Seller refurbished

Shop Categories

All Categories

We buy, sell and rent general purpose, optical and RF test and measurement equipment. We pay top dollar for your unwanted, surplus or defective gear. Let us make you an offer on your new or used Agilent, Tektronix, Anritsu, Fluke, Rohde & Schwarz and IFR instruments.

Anritsu MP1026A Bit Master Eye Pattern Analyzer 20 GHz 10 Gbps w/ Opts 002 & 003

Item Description

Anritsu MP1026A Bit Master Eye Pattern Analyzer 20 GHz 10 Gbps with Options 002 & 003 - CALIBRATED!

You are bidding on an Anritsu MP1026A Bit Master 20 GHz 10 Gbps Eye Pattern Analyzer. It has options 002 (Clock Recovery Unit) & 003 (Optical Interface) installed and will arrive with a fresh calibration performed by an ISO 17025 accredited lab. It comes complete with the Anritsu O/E Conversion Module OEC10G-1A and all other standard accessories shown in the pictures below.

The Anritsu MP1026A Bit Master Eye Pattern Analyzer offers eye pattern measurements for data rates from 0.1 to 12.5 Gbps in a handheld, rugged, and battery-powered instrument. It is capable of sampling and displaying eye patterns or pulse patterns for high speed signals such as OC192, 10 Gbps Ethernet, and Fiber Channel. It provides convenient measurements for field or lab use and can be an excellent diagnostic tool for identifying sources of noise and jitter that degrade the signal quality.

The MP1026A Bit Master has two electrical input channels with 20 GHz of bandwidth. The clock used for measurements could be inputted by the user (0.1 to 12.5 Gbps) or derived from the data (using the optional Clock Recovery Unit 0.1 to 2.7 Gbps and 10 to 12.5 Gbps). An optional optical interface (using an external O/E module) will convert one of the electrical input channels into an optical input channel. The Bit Master allows either one or two channels to be displayed in eye or pulse mode. Time, amplitude, and histogram measurements can be made on either channel. Mask compliance testing can be used to verify whether that the input signal meets specified standards (using the built-in or user defined masks). Time and date stamping of measurement data is automatic. The internal memory provides for the storage and recall of more than 1000 measurement setups. The bright daylight-viewable, high-resolution color liquid crystal display (LCD) provides easy viewing in a variety of lighting conditions.

Specifications:

Clock Trigger Frequency: 0.1 to 12.5 GHz

Clock Trigger Sensitivity: 80 mVp-p, typical (>=1 GHz), 200 mVp-p, typical (<1 GHz)

Maximum Clock Trigger: 2 Vp-p, maximum input

Jitter, RMS (when measured with a non-divided clock): 5 to 12.5 GHz: 1 ps typical, 1.5 ps maximum; 1 to 5 GHz: 1 ps typical; 0.1 to 1 GHz: 2 ps typical

Eye Mode Scale Factor: 1 UI minimum full scale. Pattern Mode Scale Factor: 1 bit minimum full scale

Vertical System. Input Range: ±500 mV offset, minimum; ±400 mV dynamic range, minimum; ±2V maximum input before damage

Bandwidth (-3dB): DC to 20 GHz, minimum; DC to 25 GHz, typical; Flatness: ±1 dB, typical. Noise, RMS: 0.75 mV typical, 1.75 mV maximum

Digital System Sampling Speed: 100 ksamples/sec typical

Clock Recovery (Option 002): Clock Rates 9.8 to 12.5 GHz, 0.1-2.7 GHz

Option 003 - Optical Interface Option (requires O/E Conversion Module OEC10G-1A)

You can view the specs for this unit here: Product Specs

This unit is in excellent condition, has been fully tested and is guaranteed functional. It comes w/ a 14 day right of return should it not perform to your expectations. Please review pics and text carefully before bidding to verify accuracy of description. If you don't see it in the pictures, it is not included.
